Flat ribbon cable

6243Y 3-Core Triple & Earth Cable Grey flat cable

flat cable
Product description: 6243Y 3-Core Triple & Earth Cable Grey flat cable which is mainly used for two way and intermediate lighting circuits in domestic locations and for Central Heating wiring. Fixed installation in both d
INQUIRY

6243Y 3-Core Triple & Earth Cable Grey flat cable which is mainly used for two way and intermediate lighting circuits in domestic locations and for Central Heating wiring. Fixed installation in both dry and damp walls, Cable Trunking & Cable Tray or embedded in plaster. It is recommended for areas which are of a fire risk which have a large presence of people due to its excellent fire retardant, reduced fume toxic, and toxic/corrosive gas emissions. flat cable Suitable for fixed applications in indoor (both dry and humid environment), outdoor and metallic structures. Good resistance to humidity, chemical agents and solar radiation.6242Y 2.5mm² 2-Core Grey flat Cable

Grey flat cable

6243Y 3-Core Triple & Earth Cable Grey flat cable 1.5mm Conductors are Solid with the CPC earth being 1.0mm also, and rated in normal conditions at around 16 Amps. Also available in cut metre lengths, 25m and 50m Coils.
6243Y 3-Core Triple & Earth Cable Grey flat cable Not suitable for unprotected use outside as the outer sheath are vunerable to attack from UV, however Alkyd paint is enough to protect it from UV.
4 solid conductors (Black, Brown, Grey and 1.0mm Bare Earth)
Voltage Range 300/500 Volts
Temperature Range Between -15 to+ 70 oC
Overall Sandard - BS6004:2012 Table 4
Conductor Standard - BS EN 60228
Insulation Standard - PVC Type 1 to BS EN 50363-3.2005
Sheath Standard - PVC BS7655-4.2000
Nominal Overall DImensions - 5.0mm x11.4mm
