PUR polyurethane cable

Control PUR-JZ Cable

Control PUR-JZ Cable
PUR-JZ Cable
Product description: Control PUR-JZ Cable has a tough polyurethane (PUR) outer sheath. Designed for connecting, measuring, checking and control applications in the machine, plant and tool making industries. The PUR sheath
INQUIRY

Control PUR-JZ Cable has a tough polyurethane (PUR) outer sheath. Designed for connecting, measuring, checking and control applications in the machine, plant and tool making industries. The PUR sheath provides increased mechanical and chemical resistance when compared to standard PVC.
Control PUR-JZ Cable Material:
stranded bare copper, stranding as per VDE 0295, class 5
Insulation:
Material: PVC
Core identification:number coded black cores with white numbers + green/yellow,
Sheath: PUR grey RAL 7001 or other colour.
Voltage: 300/500V
Test voltage: 3000V
Operating temperatue range: -5°C to +80°C flexing ;-40°C to +90°C fixed
Minimum bending radius: 12-15 x cable diameter.
PUR-OZ = without earth, PUR-JZ = with earth (included in core count).

Control PUR-JZ Cable is suitable for installation indoors or outdoors, in dry, moist or wet areas including where exposed to harsh mechanical strain or dragged over sharp/rough surfaces. These cables are resistant to mineral oils, coolant emulsions and UV-radiation.

Control PUR-JZ Cable is extremely robust cable used mostly for its good tear and abrasion resistance. Due to its good resistance against mineral oils and coolants the cable is ideal for use in machinery, tool making and heavy industry in critical areas. The cable is easy and fast to install due to its high abrasion resistance and good flexing characteristics. The PUR cable is ideal for drag chains due to its small bending radius. The cable is also resistant to UV radiation, oxygen, ozone, hydrolysis and microbes and is therefore suitable for open air use.
