Rubber cable

  • H01N2-D rubber arc-welding cable, 100 VAC, 150 DC
H01N2-D rubber arc-welding cable, 100 VAC, 150 DC

H01N2-D rubber arc-welding cable, 100 VAC, 150 DC

  • H01N2-D rubber arc-welding cable
  • Product description: H01N2-D rubber arc-welding cable, 100 VAC, 150 DC is used to connect the welding generator, manual electrode and workpiece. Used in the automotive industry, shipbuilding, transportation and transporta
  • INQUIRY
H01N2-D rubber arc-welding cable, 100 VAC, 150 DC is used to connect the welding generator, manual electrode and workpiece. Used in the automotive industry, shipbuilding, transportation and transportation systems, tool manufacturing machinery, welding robots, etc. Even if affected by ozone, light, oxygen, protective gas, oil and gasoline, this cable maintains its high flexibility. Their durable cable structure makes them resistant to low temperature, high temperature, fire, ozone, radiation, oil, acid, fat and gasoline. Suitable for outdoor installation in dry or humid places.
H01N2-D rubber arc-welding cable, 100 VAC, 150 DC structure
-Multi-strand super-soft bare copper conductor
-Follow DIN VDE 0295, BS 6360, IEC 60228, HD 383
-Polyester insulation
-Neoprene sheath EM5
H01N2-D rubber arc-welding cable, 100 VAC, 150 DC Technical characteristics
-Operating voltage: 100/100 V
-Test voltage: 1000 V
-Dynamic bending radius: 12.0 x Ø
-Fixed installation bending radius: 7.5 x Ø
-Operating temperature during application: -25º C to + 80º C
-Fixed installation temperature: -40º C to + 80º C

-Flame retardant: IEC 60332.1
