Control Cable

KVVR cable

Control Cable
Product description: KVVR cable|kvvr flexible control cable is a PVC insulated PVC sheathed control cable suitable for the wiring of control, signal, protection and measurement systems with a rated voltage of 450/750V and
INQUIRY

KVVR cable|kvvr flexible control cable is a PVC insulated PVC sheathed control cable suitable for the wiring of control, signal, protection and measurement systems with a rated voltage of 450/750V and below or 0.6/1kV and below, according to GB9330 "Plastic Insulated Control Cable", IEC60227 "Polyvinyl chloride insulated cables with rated voltages up to and including 450/750V" and IEC60502 "extruded insulated power cables with rated voltages of 1-30kV and accessories" and other standards.
KVVR cable|kvvr flexible control cable Use characteristics
●The rated power frequency voltage Uo/U is 450/750V.
●The allowable long-term maximum working temperature of the cable conductor is 70℃.
●The ambient temperature during cable laying should not be lower than 0℃. If the ambient temperature is lower than 0℃, the cables should be preheated.
●The recommended allowable bending radius of the cable is as follows:
Non-armored cables should be no less than 6 times the outer diameter of the cable; (KVVR cables belong to this category)
Armored or copper tape shielded cables should not be less than 12 times the outer diameter of the cable;
The shielded flexible cable should not be less than 6 times the outer diameter of the cable.
Introduction of KVVR cables and related models
