Teflon insulated PVC sheathed high temperature shielded control flexible cable
high temperature shielded control flexible cable
Product description: Fluoroplastics have high chemical stability, chemical corrosion resistance, fire resistance, high temperature resistance, flame retardant and other characteristics, so it has a wide range of applicati
Fluoroplastics have high chemical stability, chemical corrosion resistance, fire resistance, high temperature resistance, flame retardant and other characteristics, so it has a wide range of applications in the wire and cable industry. The single-core cable or coaxial cable is twisted together to facilitate multi-core cable. Among them, there are twisted pairs and non-twisted pairs, which are used for industrial computer control and automatic instrument control respectively. For special occasions, such fluoroplastic cables are also used for five or more types of cables, data transmission, audio and video transmission, etc. Teflon insulated PVC sheathed high temperature shielded control flexible cable structure characteristics: Conductor material: multi-strand oxygen-free copper wire Insulation Material: Fluoroplastics Insulation Shielding material: braided copper wire shielding Sheath Material: PVC Sheath Core color: within 5 cores, color distinction, white numeral number of black cores above 5 cores Flame Retardant: IEC 60332 Working Voltage: 300/500V Out-of-factory test voltage: 2000V-3000V Minimum bending radius: cable outer diameter * 8 times The long-term working temperature should not be higher than + 200 C, and the long-term working temperature should not be lower than - 20 C. We can customize any high temperature cable you need according to your requirements. Welcome to communicate. Fluoroplastic cables have been used more and more in industrial automation control. Fluoroplastic cables are a good choice in metallurgical, petrochemical, power plant and other high temperature environments. In addition, fluoroplastic cables can be widely used in high-rise buildings, underground shopping malls, tunnels, hotels and hospitals because of their flame retardant and less smoke when burning.
