Halogen-Free, Single Core, 1.8/3kV NSHXAFÖU cable

Halogen-Free, Single Core, 1.8/3kV NSHXAFÖU cable

  • NSHXAFÖU cable
  • Product description: Halogen-Free, Single Core, 1.8/3kV NSHXAFÖU cable is 1.8/3kV, EPR insulated, black halogen-free polymer jacketed single conductor cable.
  • INQUIRY

Halogen-Free, Single Core, 1.8/3kV NSHXAFÖU cable  is 1.8/3kV, EPR insulated, black halogen-free polymer jacketed single conductor cable. This oil-resistant and flame-retardant cable is particularly suitable for protection against short circuits in laying and for inherently earth-fault-proof routing in trains and buses. See similar cables:NSHTÖU Cable
Halogen-Free, Single Core, 1.8/3kV NSHXAFÖU cable Construction:
Fine tinned copper strands
Strands to VDE-0295 Class-5, IEC-60228 CL-5
EPR Rubber (3GI3) core insulation
Halogen-free polymer (GM3) outer jacket
Black (RAL 9005)
Oil & chemical resistant

Dimension (mm2) Outher diameter (mm) Copper weight (kg/km) Weight appr.
(kg/km)
1 x 1,5 5,9 14,4 62
1 x 2,5 6,2 24 76
1 x 4 6,8 38 95
1 x 6 7,4 58 140
1 x 10 8,7 96 190
1 x 16 9,5 154 270
1 x 25 11,9 240 410
1 x 35 13,1 336 490
1 x 50 14,5 480 650
1 x 70 16,3 672 900
1 x 95 19,2 912 1200
1 x 120 21,0 1152 1450
1 x 150 22,8 1440 1800
1 x 185 24,8 1776 2200
1 x 240 27,1 2304 2650
1 x 300 30,3 2880 3250

Halogen-Free, Single Core, 1.8/3kV NSHXAFÖU cable Technical:

  • Working voltage: 1800/ 3000 volts
  • Testing voltage: 6000 volts
  • Flexing bending radius: 10 x Ø
  • Static bending radius: 6 x Ø
  • Flexing temp: -5º C to +100º C
  • Static temp: -25º C to +100º C
  • Flame retardant: IEC 60332.1
  • Insulation resistance: > 20 MΩ x km
Halogen-Free, Single Core, 1.8/3kV NSHXAFÖU cable is suitable for laying in dry environments. Maximum permissible operating voltage for three-phase and one-phase alternating current operations in Uo/U 2.1/3.6kV. For direct current operation Uo/U is 2.7/5.4kV.NSGAFÖU Cable
