Product description: NSHTÖU-K Crane Cable is to be used as a connection cable for reeling purposes for very high mechanical loads on movable appliances, mobile line carriers, cable carriages as well as for vertical drum o
INQUIRY

NSHTÖU-K Crane Cable is to be used as a connection cable for reeling purposes for very high mechanical loads on movable appliances, mobile line carriers, cable carriages as well as for vertical drum operation. It is also applicable for the scope of DIN VDE 0168 and 0118, for underground and open-cast mines,NSGAFÖU Cable.

NSHTÖU-K Crane Cable Construction:

1 ..... fine-stranded tinned copper
2 ..... core insulation of rubber compound (EPR)
3 ..... inner sheath of rubber ( 5GM2) with open plaiting out of plastic
threads to protect the cable from torsion
4 ..... outer sheath of polychloroprene (5GM2), black,
oil resistant and flame retardant
NSHTÖU-K Crane Cable CHARACTERISTICS

Voltage Rating (Uo/U) 0.6/1kV

Temperature Rating

Fixed: -45°C to +60°C

Flexed: -25°C to +60°C

Minimum Bending Radius Fixed: 4 x overall diameter

Flexing: 5 x overall diameter

Maximum Tensile Load 20 N/mm2

Travel Speed In festoon: up to 240m/min In reeling: up to 120m/min horizontal
